Armor Plated Universal

×

The Armor Plated Universal Mount can be used in the same applications as the standard Universal Mounts. But since it has bonded-in steel wear surfaces, it can be used in more extreme environments. These steel wear surfaces eliminate the need for machining a radius in the support structure. Standard elastomer is neoprene and inserts are zinc-plated steel.
CLICK TO VIEW CATALOG PAGE





Item #
Color Code
Max Radial Load
Max Axial Load
Snubbing Washer
Price
Qty to Add
60270-1
Yellow
35 lbs
100 lbs
00182
(not included)
60270-2
Red
45 lbs
150 lbs
00182
(not included)
60270-3
Green
55 lbs
200 lbs
00182
(not included)
60270-4
Blue
65 lbs
250 lbs
00182
(not included)
60270-5
White
80 lbs
300 lbs
00182
(not included)
